4K HDMI 2.0 Fiber Converter OM4 Multi Mode Transmitter Receiver 300 Meters

Name: 4K HDMI 20 Fiber Converter OM4 Multi Mode Transmitter Receiver 300 Meters
Brand: E-link
Price: 1 USD

China 4K HDMI 2.0 Fiber Converter OM4 Multi Mode Transmitter Receiver 300 Meters factory

Brand Name : E-link

Model Number : LNK-108M

Certification : CE,FCC,RoHs

Place of Origin : China

MOQ : 1 pair

Price : Negotiation

Payment Terms : Western Union, L/C, T/T, MoneyGram

Supply Ability : 2000 pcs/per month

Delivery Time : 7 working days

Packaging Details : 4K HDMI Fiber Transmitter Receiver Standard Export Package

Product Name : 4K 30Hz HDMI 2.0 Fiber Transmitter & Receiver

Compatibility : HDMI 2.0

Fiber Cable : OM4 Multi Mode

Fiber Type : Single fiber LC

Transmission Rate : 18Gbps

Website Specifications : Color space 444, 420, 400

EDID : Support

HDCP : Support

CEC : Support

Weight : 0.1 kg/pair

Contact Now

4K HDMI 2.0 Fiber Converter OM4 Multi Mode Transmitter & Receiver 300 Meters

HDMI Over Fiber Extender Advantages
►Supports HDMI2.0 Video up to 4K/60Hz (Y:U:V 4:4:4)
►No Settings or Adjustments Necessary
►Adopt WDM technology to realize high-definition audio and video transmission through a single OM4 multi-mode optical fiber
►Supports up to 300m Transmission Distance with OM4 multimode fiber
►The TMDS signal is transmitted through a multimode optical fiber, which has good anti-interference performance
►Support EDID, HDCP, CEC transparent transmission

HDMI Video Fiber Transmitter Receiver 4K 30Hz Technical Indexes

Type of Extender	Mini 4K/60Hz HDMI2.0 Fiber Extender over Single-Core Multimode
Video Support	4K@60Hz/4K@30Hz/1080p/1080i/720p
Audio Support	Dolby TrueHD, Dolby Digital Plus, DTS, DTS-ES 6.1, DTSHD, DTS-HD-HRA, DTS-HD Master, (PCM-2CH)
EDID	Support
HDCP	Support
CEC	Support
Fiber Connector	1 x LC Connector
Transmission Rate	18Gbps(6Gbps/CH)
Transmission Distance	OM4 Multi Mode, up to 984ft (300M)
Operating Temperature	-40°C to + 70°C
Storage Temperature	-20°C to + 85°C
Humidity	to 90% RH (non-condensing)
Safety Approvals	CE, RoHS, FCC
Dimension (WxDxH)	2.24 x 0.6 x 0.55 in (57x16x14mm)
Weight	0.1 kg / 0.22 lb
Operation Voltage	5VDC
Operation Current	TX:150mA
Power Consumption	TX: <800mW; RX: <400mW

4K HDMI 2.0 To Fiber Transceivers Overview
The LNK-108M is a mini 4K/60Hz HDMI2.0 single core MM compact fiber optic extender that can be directly inserted into the device. Use this extremely compact device to expand your 4K video source to 984 feet/300 meters through fiber optics, achieving the display you want. This package can also promote secure data, while RFI/EMI emissions are negligible or video quality is lost due to the absence of copper conductors. This product is an ideal choice for large screen displays, conference systems, and home entertainment. This device has anti-interference ability to ensure signal stability.
4K HDMI 2.0 Fiber Converter OM4 Multi Mode Transmitter Receiver 300 Meters

4K HDMI 2.0 Fiber Converter OM4 Multi Mode Transmitter Receiver 300 Meters

4K HDMI Video Fiber Transmitter Receiver Ordering Information

Model	Description
LNK-108M	Mini 4K/60Hz HDMI2.0 over Fiber Extender , OM4 Multi-mode Fiber, 300 meters, LC, including 1 transmitter & 1 receiver, used by pairs, USB Power Input
