Mini 4K HDMI Fiber Extender With RS232 And External Audio 5VDC Type C Power Input

  • 1
  • 2

Brand Name : E-link

Model Number : LNK-MHRA4K

Certification : CE,FCC,RoHs

Place of Origin : China

MOQ : 1 pair

Price : Negotiation

Payment Terms : Western Union, L/C, T/T, MoneyGram

Supply Ability : 2000 pairs/month

Delivery Time : 7 days

Packaging Details : HDMI Fiber Optic Converter standard export package

Keywords : HDMI Fiber Optic Extender

Video Support : 4Kx2K 30Hz

Fiber Connector : SFP / LC

RS232 Baud Rate : 38400

Transmission Distance : Up to 80km

Casing : IP40 Aluminum shell

Contact Now

Mini 4K HDMI Fiber Extender With RS232 And External Audio 5VDC Type-C Power Input

HDMI Video Fiber Converter Advantages

►HDMI 1.4a and HDCP1.2 Support
►Transmission distance up to 80km over fiber cable
►Support external stereo audio
►Support Serial RS232 Signal
►Miniature form factor for ease of use and installation


Audio Fiber Optic Converter Max Resolution Support

Chroma subsampling 4:4:4 4:2:2 4:2:0
HDMI 4K@30Hz 4K@30Hz 4K@60Hz
DVI 4K@30Hz 4K@30Hz 4K@60Hz

HDMI Extender with RS232 Technical Indexes

Video Support Up to 720P/960P/1080p@60Hz, 4K*2K@30Hz
Audio Support Dolby TrueHD, Dolby Digital Plus, DTS, DTS-ES 6.1, DTSHD, DTS-HD-HRA, DTS-HD Master, (PCM-2CH)
Chroma Subsampling

Max 3840*2160@60Hz (4:2:0)

Max 3840*2160@30Hz (4:4:4, 4:2:2)
EDID

Bi-Directional (Forward + Backward) Transmission:

Support Dynamic EDID, Plug & Play, no need to learn

Single-Directional (Forward) Transmission:

Support EDID learning manually
Audio Interface 3.5MM external stereo audio
RS232 3 Pin terminal, Baud rate ≤ 38400
Fiber Connector SFP/LC
Bandwidth 10.2Gbps
Transmission Distance 300m (Over OM3 Fiber)
Up to 80km (Over Single-mode Fiber)
Operating Temperature -10 to + 50°C
Dimension (WxDxH) 2.87 x 1.73 x 0.69in (73x44x17mm)
Weight 60g / 0.13 lb
Power Supply 5V DC, USB Typ-C

Fiber Optical Transmitter Receiver Overview

The Transmitter converts an HDMI signal to a single 10Gb/s serial data stream for transmission over optical fiber. The Receiver converts the serial data back to an HDMI signal. The transceivers are RoHS compliant and lead-free per requirements in Europe and China. This product is ideal for large-screen display, conferencing systems and home entertainment and so on. The device has the ability of anti-interference, to ensure the stability of the signal.

Mini 4K HDMI Fiber Extender With RS232 And External Audio 5VDC Type C Power Input

Mini 4K HDMI Fiber Extender With RS232 And External Audio 5VDC Type C Power Input

Micro HDMI over Audio Transceiver Ordering Information

Model Description
LNK-MHRA4K-MM Mini HDMI Fiber Extender: 1Ch HDMI Signal(4K*2K) + 1Ch Stereo Audio + Backwards RS232, OM3 Multi-mode Fiber, 300 meters, LC, including 1 transmitter & 1 receiver, 5V DC Type-C Power Input
LNK-MHRA4K-S20 Mini HDMI Fiber Extender: 1Ch HDMI Signal(4K*2K) + 1Ch Stereo Audio + Backwards RS232, Single-mode Fiber, 20km, LC, including 1 transmitter & 1 receiver, 5V DC Type-C Power Input
LNK-MHRA4K-S40 Mini HDMI Fiber Extender: 1Ch HDMI Signal(4K*2K) + 1Ch Stereo Audio + Backwards RS232, Single-mode Fiber, 40km, LC, including 1 transmitter & 1 receiver, 5V DC Type-C Power Input
LNK-MHRA4K-S80 Mini HDMI Fiber Extender: 1Ch HDMI Signal(4K*2K) + 1Ch Stereo Audio + Backwards RS232, Single-mode Fiber, 80km, LC, including 1 transmitter & 1 receiver, 5V DC Type-C Power Input
